Bentley RAM Connection Standalone 23.00.00.190 | โปรแกรมวิเคราะห์การเชื่อมต่อโครงสร้างเหล็ก

Bentley RAM Connection logo



ดาวน์โหลด โปรแกรม Bentley RAM Connection Standalone / Elements / Structural System 23.00.00 | โปรแกรมออกแบบและวิเคราะห์การเชื่อมต่อโครงสร้างเหล็ก ฟรี





โปรแกรม Bentley RAM Connection Standalone: ซอฟต์แวร์ออกแบบและวิเคราะห์จุดต่อโครงสร้างเหล็ก

Bentley RAM Connection Standalone คือซอฟต์แวร์สำหรับการออกแบบและวิเคราะห์การเชื่อมต่อโครงสร้างเหล็ก ที่พัฒนาโดย Bentley Systems สำหรับการออกแบบและวิเคราะห์การเชื่อมต่อโครงสร้างเหล็กในด้านวิศวกรรมโครงสร้าง ซอฟต์แวร์ตัวนี้เป็นส่วนหนึ่งของชุดโปรแกรม RAM Structural System ซึ่งรวมเครื่องมือต่างๆสำหรับการวิเคราะห์และออกแบบโครงสร้าง

RAM Connection เป็นทางออกที่เหมาะสมเมื่อวิศวกรโครงสร้างหรือนักออกแบบต้องการตรวจสอบการเชื่อมต่อเฉพาะจุด ออกแบบการเชื่อมต่อเพียงจุดเดียวที่มีหลายข้อต่อ หรือต้องการปรับแต่งการเชื่อมต่อแต่ละจุดในโครงสร้างให้เหมาะสมที่สุด นอกจากนี้ ซอฟต์แวร์สามารถวิเคราะห์ ออกแบบ และตรวจสอบการเชื่อมต่อโครงสร้างเหล็กได้อย่างครอบคลุม รวมถึงการคำนวณการรองรับแรงแผ่นดินไหว Bentley RAM Connection ช่วยให้สามารถออกแบบการเชื่อมต่อได้โดยบูรณาการกับ RAM Structural System, RAM Elements และ STAAD.Pro หรือจะใช้เป็นโปรแกรมแบบสแตนด์อโลนสำหรับการออกแบบการเชื่อมต่อโครงสร้างเหล็กก็ได้เช่นกัน

จุดเน้นหลักของ RAM Connection Standalone คือการออกแบบการเชื่อมต่อโครงสร้างเหล็ก ซึ่งเป็นส่วนสำคัญในการถ่ายโอนน้ำหนักระหว่างส่วนต่างๆ ของโครงสร้าง รวมถึงเพื่อความมั่นคงและความสมบูรณ์ของโครงสร้างโดยรวม ซอฟต์แวร์นี้จัดเตรียมชุดเครื่องมือและคุณสมบัติที่ครอบคลุมให้กับวิศวกรเพื่อสนับสนุนกระบวนการออกแบบ

โปรแกรม Bentley RAM Connection Standalone เป็นซอฟต์แวร์สำหรับการออกแบบและวิเคราะห์จุดต่อโครงสร้างเหล็ก โปรแกรมนี้ช่วยวิศวกรโครงสร้างในการ:

  • ออกแบบจุดต่อเหล็กทุกประเภทตามมาตรฐานการออกแบบต่างๆ เช่น AISC, EN 1993, BS 5950, IS 800, GB 50017, AS4100 และ NZS 3404
  • วิเคราะห์แรงกระทำจากแผ่นดินไหว และแรงอื่นๆ ที่จุดต่อ
  • ตรวจสอบว่าจุดต่อมีความปลอดภัย และมีประสิทธิภาพ
  • เพิ่มประสิทธิภาพ การออกแบบจุดต่อโดยใช้เครื่องมืออัตโนมัติ
  • สร้างแบบจำลอง 3D ของจุดต่อ
  • สร้างรายงาน การออกแบบ

คุณสมบัติหลักของโปรแกรม Bentley RAM Connection Standalone:

  • ใช้งานง่าย: อินเทอร์เฟซผู้ใช้ที่ใช้งานง่าย ช่วยให้ผู้ใช้สามารถเริ่มใช้งานโปรแกรมได้อย่างรวดเร็ว
  • ครอบคลุม: รองรับการออกแบบจุดต่อเหล็กทุกประเภท
  • แม่นยำ: การคำนวณที่แม่นยำ ช่วยให้มั่นใจได้ว่าจุดต่อมีความปลอดภัย
  • มีประสิทธิภาพ: เครื่องมืออัตโนมัติ ช่วยเพิ่มประสิทธิภาพ การออกแบบ
  • การผสานรวม: ทำงานร่วมกับโปรแกรม Bentley อื่นๆ เช่น RAM Structural System, RAM Elements และ STAAD.Pro

ข้อดีของการใช้โปรแกรม Bentley RAM Connection Standalone:

  • ประหยัดเวลา: ช่วยให้วิศวกรโครงสร้างออกแบบและวิเคราะห์จุดต่อได้รวดเร็ว
  • ประหยัดเงิน: ช่วยลดต้นทุน การออกแบบและก่อสร้าง
  • เพิ่มความปลอดภัย: ช่วยให้มั่นใจได้ว่าจุดต่อมีความปลอดภัย
  • เพิ่มประสิทธิภาพ: ช่วยให้เพิ่มประสิทธิภาพ การออกแบบ

โปรแกรม Bentley RAM Connection Standalone เหมาะสำหรับวิศวกรโครงสร้างที่ต้องการออกแบบและวิเคราะห์จุดต่อเหล็กอย่างมีประสิทธิภาพ และแม่นยำ



Features:

Design Codes and Standards:

  • Global Reach: Supports a wide range of international design codes including AISC (ASD and LRFD), EC3, BS5950, IS800, GB50017, AS4100, and more.
  • Seismic Design: Includes capabilities for seismic design and detailing.

Connection Types:

  • Versatility: Designs and details an extensive array of connections such as:
    • Beam-to-column (flange and web)
    • Beam-to-girder
    • Beam and column splices
    • Braced frame connections
    • Complex multi-member connections
    • Column base plates
    • Vertical and horizontal gusset connections

Workflow and Optimization:

  • Efficiency: Streamlines the design process with powerful analysis and design capabilities for rapid connection design.
  • Customization: Provides a library of standard connection types, but also allows modification and the creation of custom connections.
  • Optimization: Aids in finding the most economical and practical connection configurations.

Integration:

  • Bentley Ecosystem: Works seamlessly with other Bentley structural products like RAM Structural System, RAM Elements, and STAAD.Pro, enabling smooth data exchange of model geometry, joint data, and loads.
  • Standalone Capability: Can also function as a standalone application for designing connections without the need for other structural software.

Documentation and Detailing:

  • Automatic Drawing Generation: Produces detailed shop drawings and fabrication documentation.
  • Comprehensive Reports: Provides thorough calculation reports including forces, geometry, and code compliance checks.



Screenshot

Bentley RAM Connection 23

Bentley RAM Connection 23

System Requirements

Windows 10 / 11 (64-bit – all editions)
Processor: 1.3 GHz or faster processor (x64)
RAM: 2 GB minimum, 4 GB recommended
Hard Disk: 675 MB free disk space for installation
2 GB available for analyzing models
Display: Open GL compatible graphics card with at least 512 MB in video memory,
1024×768 minimum screen resolution.
File Info

Official Website : https://www.bentley.com/software/ram-connection/
License : Trial
Software Version
: 23.00.00.190 File Name : BRAMCS23.00.00.190.rar File Size : 2.65 GB File Type : *.rar Server : Pixeldrain | Google Drive Upload date : 27/02/2024 Last modified : 27/02/2024 Password : sbz

💾 ดาวน์โหลด

รหัสแตกไฟล์คือ sbz
วิธีดาวน์โหลด | วิธีแก้ลิ้งค์เกินโควต้า


" This file is for trial/educational and non-commercial use only. Using non-genuine software may cause various problems to use this software without any problems Please purchase a genuine license from the official website. "
